Forging
Forging Machinery List
| CUTTING SHOP | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Wire rope hoist | CS-CR-01 | Ganesh | 5 Ton (5000 kg) | Cutting Chop | April - 2012 | |
| 2 | Bandsaw Cutting Machine | CS C 01 | Laxson | Max 320mm | Cutting Chop | April - 2012 | |
| 3 | Bandsaw Cutting Machine | CS C 02 | Laxson | Max 320mm | Cutting Chop | April - 2012 | |
| 4 | Bandsaw Cutting Machine | CS C 01 | Laxson | Max 120mm | Cutting Chop | April - 2012 | |
| DIE SHOP | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Lathe Machine | DS 01 | Tirupati | 7'15"15" | Die Shop | April - 2018 | |
| 2 | Welding Machine | DS 02 | Die Shop | April - 2010 | |||
| 3 | Grinder | DS 03 | --- | Die Shop | April - 2010 | ||
| 4 | Drill Machine | DS 05 | --- | Die Shop | April - 2012 | ||
| 5 | Drill Machine | DS 06 | --- | Die Shop | April - 2015 | ||
| FORGE SHOP UNIT - 1 | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Air Compressor | FS AC 1 | ELGI | 25 HP Working pressure - 8 Bar | Forge Shop | April - 2018 | |
| 2 | Wire Rope Hoist | FS-UI-1-CR-01 | Ganesh | 5 Ton (5000 kg) | Forge Shop | April - 2012 | |
| 3 | Wire Rope Hoist | FS-CR-02 | Ganesh | 10 Ton (10000 kg) | Forge Shop | April - 2012 | |
| FORGE SHOP-(UNIT-1)-LINE-1 (OD 80mm - 350mm HEIGHT 30mm TO 100mm WT, UPTO 25KG) | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Induction Billet Heater | FS-UI-1-LI-2 1A | Plasma | 375 KW/1200Kg/Hrs | Forge Shop Unit-1 | April - 2019 | |
| 2 | Power Press | FS-UI-1-LI-2 1B | Amrit | 200 Ton 7" Stroke | Forge Shop Unit-1 | April - 2008 | |
| 3 | Power Press | FS-UI-1-LI-2 1C | Amrit | 300 Ton 8" Stroke | Forge Shop Unit-1 | April - 2008 | |
| 4 | Power Press | FS-UI-1-LI-2 1D | Amrit | 80 Ton 6" Stroke | Forge Shop Unit-1 | April - 2008 | |
| 5 | Ring Rolling | FS-UI-1-LI-2 1E | Self Made | 80 to 350mm Outside Dia. | Forge Shop Unit-1 | April - 2008 | |
| 6 | Power Press | FS-UI-1-LI-2 1F | Amrit | 250 Ton 8" Stroke | Forge Shop Unit-1 | April - 2008 | |
| FORGE SHOP-(UNIT-1)-LINE-2 (OD 250mm - 600mm HEIGHT 50mm TO 280mm WT, UPTO 100KG) | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Furnace (Oil Fired) | FS-UI-1-LI-2 2A | Self Made | 1000Kg/Hrs | Forge Shop Unit-1 | April - 2012 | |
| 2 | Power Press | FS-UI-1-LI-2 2B | Amrit | 3500 Ton 10" Stroke | Forge Shop Unit-1 | April - 2012 | |
| 3 | Power Press | FS-UI-1-LI-2 2C | Amrit | 400 Ton 11" Stroke | Forge Shop Unit-1 | April - 2012 | |
| 4 | Power Press | FS-UI-1-LI-2 2D | Amrit | 100 Ton 8" Stroke | Forge Shop Unit-1 | April - 2012 | |
| 5 | Ring Rolling | FS-UI-1-LI-2 2E | Indian | 250 to 600mm | Forge Shop Unit-1 | April - 2012 | |
| 6 | Power Press | FS-UI-1-LI-2 2F | Amrit | 400 Ton 11" Stroke | Forge Shop Unit-1 | April - 2012 | |
| FORGE SHOP-(UNIT-1)-LINE-3 (OD 300mm - 1100mm HEIGHT 50mm TO 300mm WT, UPTO 400KG) | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Furnace (Oil Fired) | FS-UI-1-LI-2 3A | Self Made | 1500Kg/Hrs | Forge Shop Unit-1 | April - 2016 | |
| 2 | Hydraulic Press | FS-UI-1-LI-2 3B | Indian | 500 Ton 10" Stroke | Forge Shop Unit-1 | April - 2016 | |
| 3 | Ring Rolling | FS-UI-1-LI-2 3C | China | 350 to 1100mm Outside Dia. | Forge Shop Unit-1 | April - 2016 | |
| 4 | Belt Drop Hammer | FS-UI-1-LI-2 3E | NKH | 3 Ton | Forge Shop Unit-1 | April - 2017 | |
| FORGE SHOP-(UNIT-2)-LINE-1 (OD 50mm - 150mm HEIGHT 25mm TO 55mm WT, UPTO 3KG) | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Wire Rope Hoist | FS-UI-2-CR-01 | Ganesh | 5 Ton (5000Kg) | Forge Shop Unit-2 | April - 2009 | |
| 2 | Induction Billet Heater | FS-UI-2-LI-1 1A | Plasma | 150 KW/600Kg/Hrs | Forge Shop Unit-2 | April - 2011 | |
| 3 | Power Press | FS-UI-2-LI-1 1B | Mankoo | 150 Ton 6" Stroke | Forge Shop Unit-2 | April - 2009 | |
| 4 | Power Press | FS-UI-2-LI-1 1C | Kawa | 150 Ton 6" Stroke | Forge Shop Unit-2 | April - 2009 | |
| 5 | Power Press | FS-UI-2-LI-1 1D | Amrit | 50 Ton 6" Stroke | Forge Shop Unit-2 | April - 2009 | |
| 6 | Ring Rolling | FS-UI-2-LI-1 1E | Gahir | 50 to 150mm | Forge Shop Unit-2 | April - 2009 | |
| 7 | Power Press | FS-UI-2-LI-1 1F | Basant | 250 Ton 6" Stroke | Forge Shop Unit-2 | April - 2009 | |
| FORGE SHOP-(UNIT-2)-LINE-2 (OD 80mm - 250mm HEIGHT 30mm TO 70mm WT, UPTO 5KG) | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Furnace | FS-UI-2-LI-2 2A | Self Made | 500kg | Forge Shop Unit-2 | April - 2009 | |
| 2 | Power Press | FS-UI-2-LI-2 2B | Amrit | 150 Ton 6" Stroke | Forge Shop Unit-2 | April - 2009 | |
| 3 | Power Press | FS-UI-2-LI-2 2C | Amrit | 150 Ton 6" Stroke | Forge Shop Unit-2 | April - 2009 | |
| 4 | Power Press | FS-UI-2-LI-2 2D | Amrit | 50 Ton 6" Stroke | Forge Shop Unit-2 | April - 2009 | |
| 5 | Ring Rolling | FS-UI-2-LI-2 2E | Self Made | 80 to 150mm | Forge Shop Unit-2 | April - 2009 | |
| 6 | Power Press | FS-UI-2-LI-2 2F | Basant | 250 Ton 6" Stroke | Forge Shop Unit-2 | April - 2009 | |
| H & T SHOP | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Wire Rope Hoist | HT-CR-01 | Induct Crane | 5 Ton (5000 kg) | H&T Shop | April - 2018 | |
| 2 | Bell Type Electric Heated Annealing Furnace | AS-01 | Axioms | 90 KW-Induction - 3 Ton Capacity | H&T Shop | April - 2018 | |
| 3 | Bell Type Electric Heated Annealing Furnace | AS-02 | Axioms | 90 KW-Induction - 3 Ton Capacity | H&T Shop | April - 2018 | |
| MACHINE SHOP | |||||||
|---|---|---|---|---|---|---|---|
| Sr. No | Machine / Equipment Description | Machine Code No. | Make | Rage/Capacity/Specification | Used For (Location/Operation) |
Installation Year | Remarks |
| 1 | Wire Rope Hoist | MS-CR-01 | Induct Crane | 5 Ton (5000Kg) | Machining Shop | April - 2018 | |
| 2 | Turning Lathes Machining | LM-01 | Tirupati | Maximum Turning Dia-600mm, Maximum Turning Length-300mm | Machining Shop | April - 2018 | |
| 3 | Turning Lathes Machine | LM-02 | Tirupati | Machining Shop | April - 2018 | ||
| 4 | Turning Lathes Machine | LM-03 | Tirupati | Machining Shop | April - 2018 | ||
| 5 | CNC Lathe Machine | TC-01 | Tirupati | Maxium Turning Dia-500mm, Maximum Turning Length -300mm | Machining Shop | April - 2018 | |
| 6 | CNC LAthe Machine | TC-02 | Tirupati | Machining Shop | April - 2018 | ||
| 7 | CNC Lathe Machine | TC-03 | Tirupati | Machining Shop | April - 2018 | ||
| 8 | CNC Lathe Machine | TC-04 | Tirupati | Maximum Turning Dia-600, Maximum Turning Length-500mm | Machining Shop | April - 2018 | |
| 9 | CNC Lathe Machine | TC-05 | Tirupati | Machining Shop | April - 2018 | ||
| 10 | CNC Lathe Machine | ACE-01 | ACE Designers | Maximum Turning Dia-400, Maximum Turning Length-540mm | Machining Shop | April - 2018 | |
| 11 | CNC Lathe Machine | ACE-02 | ACE Designers | Machining Shop | April - 2018 | ||
| 12 | CNC Lathe Machine | ACE-03 | ACE Designers | Maximum Turning Dia-400, Maximum Turning Length-540mm | Machining Shop | June - 2018 | |
| 13 | CNC Lathe Machine | ACE-04 | ACE Designers | Machining Shop | June - 2018 | ||
| 14 | CNC Lathe Machine | ACE-05 | ACE Designers | Maximum Turning Dia-600, Maximum Turning Length-500mm | Machining Shop | April - 2018 | |
| 15 | VTC Vertical Terret Lathe | ACE-06 | ACE Designers | Maximum Turning Dia-800, Maximum Turning Length-800mm | Machining Shop | April - 2018 | |
| 16 | VMC Vertical Machining Center | VMC-01 | Cosmos | Tablet Size - 800*450mm | Machining Shop | April - 2018 | |
| 17 | VMC Vertical Machining Center | VMC-02 | AMS | Tablet Size - 800*500mm | Machining Shop | April - 2018 | |
| 18 | VMC Vertical Machining Center | VMC-03 | AMS | Tablet Size - 400*500mm | Machining Shop | April - 2018 | |
| 19 | VMC Vertical Machining Center | VMC-04 | BFW | Tablet Size - 600*500mm | Machining Shop | April - 2018 | |
| 20 | CNC Wirecut Machine | WC-01 | Concord | Tablet Size - 380*525mm | Machining Shop | April - 2018 | |
| 21 | Air Compressor | AC-01 | ELGI | 25 HP working pressure - 8 Bar | Machining Shop | April - 2018 | |
